Introduction to the M3
18
e: Check box
Each time you press a check box, it alternates between
the checked (red) and unchecked states.
The parameter will be active if it is checked, and
inactive if it is unchecked.
f: Popup button (1)
When this button is pressed, a popup menu will
appear, showing the parameter values that are
available for selection.
To enter the parameter value, press the desired value
in the popup menu.
When a popup menu is displayed, using a VALUE
controller (see page 12) will close the popup menu. If
the popup menu is unlocked (see “Pin”), it will close if
you touch a location outside the popup menu. The
menu will close when you press the EXIT switch,
regardless of whether it is locked or unlocked.
* Popup menu
Pin
This switches the popup menu
display between locked and
unlocked.
When locked, the pin will be shown
closed, and the popup menu will
remain displayed even after you
press a parameter value. When
unlocked, the pin will be shown
opened, and the popup menu will
close immediately when you press a
parameter value.
g: Popup button (2)
When you press this button, a tabbed popup menu
will appear, allowing you to perform the following
selections.
• “Bank/Program Select,” “Bank/Combination
Select”: Select programs or combinations by bank
• “Multisample Select”: Select a multisample for a
program oscillator by category
• “Effect Select”: Select effects by category
• “Drumsample Select”: Select drumkit ROM
samples by category
• Select a KARMA GE
To close a tabbed menu, press the OK button or Cancel
button.
Scroll bar
Use this when you wish to see parameter values that
extend beyond what can be shown on the display at
one time.
Category button
When you press this button, a tabbed popup menu
will appear, allowing you to perform the following
selections.
• “Category/Program Select,” “Category/
Combination Select”
• Category/GE Select
Press the OK or Cancel buttons to close the tabbed
category select popup menu.
The Jump to Sub button will display a sub-category
selection menu.
h: Menu command button
* Menu
When this button is pressed, a list of menu commands
will appear.
The menu commands that appear will differ
depending on the currently selected page.
You can also select up to ten menu commands by
holding down the ENTER switch and pressing a
numeric key 0–9. The menu will close when you press
the display at a location other than the menu, or when
you press the EXIT switch.
* Dialog box
The dialog box that appears will depend on the
currently selected menu command.
When selecting a program or combination number in a
dialog box, use the VALUE controllers (see page 12) to
input the number.
To execute, press the OK button. To cancel without
executing, press the Cancel button. (The operation will
occur when you press and release the button.) The
dialog box will close. The EXIT switch corresponds to
the Cancel button, Done button, and Exit button.
Pin
Press here to scroll to left or right.
Press here and slide to left or right to
scroll to the desired location.
Press here to scroll to the
corresponding location.
Menu button
Menu
command
button
Cancel button OK button
Text edit button
