Operation and operating the device
Display Explanation
Download symbol
There is a software update available for
the inverter.
The update can be initiated in the
inverter menu by going to Service >
Updates or via the Webserver.
Globe symbol
Shows a successful connection to the
solar portal.
IP address
The IP address of the inverter is
displayed.
Insulation measurement Device performs an internal check
Grid check Device performs an internal check
Starting
Internal control measurements accord-
ing to VDE 0126
Starting, including
check of DC generators
Device performs an internal check
Feed in
Measurement successful, MPP control
active (MPP = maximum power point)
Feed-in with ext.
limitation
Feed-in is regulated on the basis of a
fault (e.g. PV energy is limited
Ch. 8,
excess temperature, fault)
Shutdown by ext. signal
The feed-in is limited as a result of
the energy supply company’s external
signal.
Event xxxx, yyyy
An event is present. Up to two active
events can be displayed. Remedial
measures can be found in the "Event
codes" chapter
Ch. 10.5
