Kostal PLENTICORE plus - Communication Connection

58
3
© 2018 KOSTAL Solar Electric GmbH
Installation
LAN
WWW
X206
Fig. 32: Communication connection
1
Inverter
2
Smart Communication Board
3
RJ45 connection socket (Ethernet/LAN)
4
LAN cable
5
Router
6
Computer / router / tablet
(for configuration or data retrieval)
The Smart Communication Board is the inverter’s
communication hub. To this end, computers, routers,
switches and/or hubs can be connected to the RJ45
connection.
If the Ethernet cable is connected to a router, the
inverter is integrated into your own network and can be
contacted by all computers incorporated in the same
network.
3.9 Communication connection
