6.3 Menu structure of Webserver
Deviations due to software versions (UI status) possible.
Home menu
Home Shows power flow diagram
Current values menu
Current values PV generator Shows voltage, current, power for each DC input
Inverter Shows inverter status and active events
Home consumption Shows the home consumption and the sources from
which the home consumption is being covered (solar
generator, battery or public grid).
Grid Shows voltage, current, power per phase and the grid
parameters
Battery If a battery is connected to the inverter, the current
battery values are displayed here
Statistics menu
Statistics Daily yield
Shows yield for current day
Monthly yield
Shows yield for current month
Annual yield
Shows yield for current year
Total yield Shows total yield
Log data menu
Log data Log data Download log data from inverter
