Operation and operating the device
Public grid menu
Shows the current energy values of the AC side.
n
Current AC power
Shows the current performance data of the grid side
(AC) and how the energy is distributed to the phases.
Parameter Explanation
Phase 1 Shows the voltage, current and
power, which is being fed into or
taken from the public grid.
Phase 2
Phase 3
n
Yield overview
Indicates the energy which has been generated by the
PV generators.
Parameter Explanation
Day Shows the yield values for the current
day (from 00 to 24 hours).
Month Shows all yield values for the current
month (from day 1 to day 31).
Year Shows all yield values for the current
year (from 1 Jan. to 31 Dec.).
Total Shows the total yield since
commissioning.
n
Grid parameter
Shows the inverter's current grid parameters.
Parameter Explanation
Current grid frequency [Hz] Shows the grid frequency.
Current cos phi [W] Indicates the current reactive power
(cos phi).
Current power Shows how much power is being fed
into the public grid or is being used by
an AC source (e.g. another inverter).
This power can then be stored in a
connected battery for example.
Limitation on [W] Shows the current power curtailment
setting.
