Part 2: Overview of display values and settings General area
17
Sensor test => Value group
(General -> Service level)
Select sensor using Ç => value is displayed
T-OUTSIDE Outside temperature
T-HS Temperature of the heat generator
T-DHW Hot water temperature
T-FLOW D 1
Flow temperature, heating circuit 1
T-ROOM D 1
Room temperature heating circuit 1
(only with remote control)
T-DHW F D 1
Storage tank charging via heat exchanger,
flow temperature HC1
T-DHW B D 1
Hot water storage tank temperature, lower
heating circuit 1
T-FLOW D 2
Flow temperature, heating circuit 2
T-ROOM D 2
Room temperature heating circuit 2
(only with remote control)
T-POOL D 2
Swimming pool temperature, heating circuit 2
T-DHW B D 2
Hot water storage tank temperature, lower
heating circuit 2
T-RETURN
T-SOLID FUEL,
T-HEADER
T-SOL PANEL
T-CIRCL
T-DHW B
T-MF1
Temperature of the multifunction sensor =>
Display according to function set for multifunc-
tion relay (see left)
T-BUFFER B For solid fuel or solar integration => Sensor in
storage tank
SENSOR TEST
Multifunction sensor according to function set for relay
01 = Header pump
=> T-HEADER = Collector temperature (display only if
sensor is connected)
20 = Temperature-controlled circulation pump
=> T-CIRCL = Temperature of circulation pipe return
21 = Circulation pump via pulse
=> no temperature display (display with ON/OFF)
Parameter LOAD THROUGH at the level Expert –Hot wa-
ter is activated (= 01)
=> T-DHW B = Temperature of the hot water tank at the in-
let area
22 = Integration of the heat generator for solid fuel
=> T-SOLID FUEL = Temperature of the heat generator for
solid fuel,
=> T-BUFFER B = Temperature of the storage tank at the
inlet area
23 = Solar integration
=> T-SOL PANEL = Temperature of the solar collector,
=> T-BUFFER B = Temperature of the storage tank in the
inlet area
24 = Return flow temperature increase
=> RETURN TEMP = Return temperature to HS
32 = Heating circuit direct => HTG CIRCUIT3 (display
ON/OFF)
T-MF1=> Temperature display without function selection
=> without sensor no display (- - - - )
