krom schroeder E8 - Sensor Values; Characteristic Curve

Remote controls Part 4: Installation and Start-up
66
Sensor values / characteristic curve
Temperature 5 kOhm NTC 1 kOhm PTC
-60 °C
698961
 470 
-50 °C
333908
 520 
-40 °C
167835
 573 
-30 °C
88340
 630 
-20 °C
48487
 690 
-10 °C
27648
 755 
0 °C
16325
 823 
10 °C
9952
 895 
20 °C
6247
 971 
25 °C
5000
 1010 
30 °C
4028
 1050 
40 °C
2662
 1134 
50 °C
1801
 1221 
60 °C
1244
 1312 
70 °C
876
 1406 
80 °C
628
 1505 
90 °C
458
 1607 
100 °C
339
 1713 
110 °C
255
 1823 
120 °C
194
 1936 
5 kOhm NTC: AF, KF, SPF, VF
1 kOhm PTC: AFS, KFS, SPFS, VFAS
The controller can be operated with 5 kOhm NTC (stand-
ard) or 1 kOhm PTC sensors. The sensor type is selected
in the start-up level during start-up.
The start-up level is displayed when the operating cover is
opened after the supply voltage has been switched on
(once only). It can be reactivated again by briefly switching
the supply voltage off.
The sensor switchover affects all sensors.
Exceptions:
 Attaching an analogue remote control is detected au-
tomatically. This means that the previous and new ver-
sions can be connected to the controller [connector I;
1 - 3 and connector III; 1 - 3].
 The controller has a facility for connecting a room sen-
sor to terminals [connector I; 1+2 and connector III;
1 + 2] and performing room temperature-dependent
control. In this case only a 5 kOhm NTC sensor can be
used, irrespective of the sensor type that has been se-
lected.
