Commissioning Part 4: Installation and Start-up
68
Commissioning
Commissioning level
All the values in this level must be entered in sequence
without interruption
Ä Open level, Ç adjust value, Ä
save value and acti-
vate next value
GERMAN Set language
TIME Set current time:
1. Minute => Ä => 2. Hour
YEAR Set current date
MONTH Set current date
DAY Set current date
BUS ID I
(see p. 69)
Enter heating circuit number"1":
00 - 15 => Standard 01
BUS ID 2
(see p. 69)
Enter heating circuit number"2":
00 - 15 => Standard 02
5K SENSORS 00 = 5 kOhm NTC sensor
01 = 1 kOhm PTC sensor
code no. required; after input, there
is a restart of the controller
Commissioning procedure
1. Please read this guide carefully before commissioning
2. Fit controller, make electrical connections and switch
on heat generator and supply voltage
3. Wait until standard display appears on controller
4. Open hinged operating cover
When the hinged operating flap is opened for the first time
after switching on, the " SETUP " is shown on the display.
5. Ä Start SETUP
6. Ç Set value
7. Ä Save value and next value
8. Close hinged operating flap (end of SETUP)
9. Move program switch to required operating mode, e.g.
automatic 1 (see page 8)
BUS- ID (Heating circuit number):
The heating circuits are sequentially numbered starting
with "01". heating circuit numbers must not be assigned
twice. Please only use "00" for replacement controllers
(see page 69).
