Display Range Part 2: Overview of display values and settings
20
Display Range
! Display only. No adjustments possible. Display only
appears if the sensor is connected and the value is
present in the system.
If the set value is not present it is masked out, or
hyphens appear in the display (- - - -).
Installation
(HG => heat generator)
Select parameter using Ç => value is displayed
T-OUTSIDE Outside temperature
T-HS DES HG temperature setting
T-HS HG flow temperature
MOD DEPTH Modulation degree of HS (BUS)
T-RETURN
T-SOLID FUEL
T-HEADER
T-SOL PANEL
T-CIRCL
CIRCL IMPULS
T-DHW B
HTG CIRCUIT3
HS return temperature
Temperature of the heat generator
for solid fuel
Header temperature
Temperature of the solar collector
Return flow temp. of the circulation
Circulation via pulse
Temp. of the hot water tank lower
measuring point (see hot water func-
tions)
Additional direct heating circuit
T-BUFFER B Buffer storage lower temperature
RETURN
Exit level using Ä
T-OUTSIDE
The measured outside temperature is smoothed for control
purposes. The smoothed value is displayed here.
T-HS DES
Corresponds to the maximum required temperature of the
consumer circuits from the heating system (incl. hot water
preparation). The mixer circuits request the temperature +
heating curve distance (expert value)
T-HS
Measured actual temperature of the heat generator
MOD DEPTH (only in the case of HS via eBUS
connection)
Only if a modulating heat generator is connected via eBUS
and transmits this value.
Temperature of the multifunction relay
T-RETURN = Return temperature of system
T-SOLID FUEL = Temperature of the heat generator for
solid fuel, => T-BUFFER B = Temperature of the
storage tank at the inlet area
T-HEADER = Collector temperature
(display only if sensor is connected)
T-SOL PANEL = Temperature of the solar collector,
=> T-BUFFER B = Temperature of the storage tank at
the inlet area
