Expert area Part 2: Overview of display values and settings
46
The parameters in this level change in accordance with the
heating circuit function that has been selected
[HC FUNCTION]
Heating circuit I / II
Designation Value range Default IV
HC FUNCTION 00 - 04 00
PUMP MODE 00 - 03 00
MIXER OPEN
(not for HW circuit)
5 - 25 18
MIXER CLOSE (not
for HW circuit)
5 - 25 12
See following pages for continuation
HC FUNCTION (heating circuit function selection)
If this parameter is modified the controller is restarted.
"RESET" briefly appears in the display.
! The special functions (02, 03, 04) must be
configured for heating circuit 2 if a normal heating
circuit (00, 01) is additionally used in the device.
00 => Standard heating circuit
01 => Control to fixed flow temperatures
During the heating periods (see heating program ) the
heating circuit is operated with a fixed
preset flow temperature
[T-FLOW DAY], and during reduced mode operation with a
fixed preset flow temperature [T-FLOW REDUC] accord-
ingly.
02 => Swimming pool control (only for heating circuit II)
This function can be used to heat a swimming pool. The
mixer controls the flow temperature for the swimming pool
heat exchanger. The swimming pool water temperature
sensor is connected to the room sensor connection for the
heating circuit (see FBR).
[Plug III; 1 + 2]
The flow temperature control operates like normal room
control [ROOM INFL].
The set value for the water temperature can be entered in
the user area of the associated heating circuit level
[T-POOL 1/2/3]. The heating program operates. No heat-
ing takes place during the reduction period (frost protection
only).
The water temperature and the current set value are dis-
played in the display level [POOL-TEMP/RATED POOL-T].
03 => Hot water circuit
This function can be used to operate additional hot water
circuits. The heating circuit flow sensor is located in the hot
water storage tank.
The hot water temperature set value can be entered in the
user area of the associated heating circuit level [T-DHW
1/2/3]. The heating program for heating circuit acts as an
enable program for the storage tank. The storage tank set
value is set to 10 °C during the reduction period.
