krom schroeder E8 - Heating Circuit I; II; Mode; T-Room des; T-Reduced

Part 2: Overview of display values and settings User Area
25
*) depending on function selector Heating circuit T-POOL,
T-DHW, T-FLOW DAY or T-FLOW REDUC (see page 46)
MODE
- - - - => The controller programming switch applies in this
case.
When setting an operating mode the mode only applies to
the assigned heating circuit. When the "i =
Standby/OFF", and "F = Summer mode" controller pro-
gramming switch operating modes are set, this has a re-
ducing effect on all heating circuits and consumer circuits
in the entire system.
T-ROOM DES 1 - 3
Required room temperature setting
T-ROOM DES 1 => used in first enable time,
T-ROOM DES 2 => used in second enable time,
T-ROOM DES 3 => used in third enable time of active
heating program for this heating circuit.
T-REDUCED
Required room temperature setting during night reduction
T-ABSENCE
Required room temperature setting during holidays
Heating circuit I / II
Designation Value range Default IV
MODE ----,i,F1,F2,B,B - - - -
T-ROOM DES 1*) 5 °C – 40 °C 20 °C
T-ROOM DES 2*) 5 °C – 40 °C 20 °C
T-ROOM DES 3*) 5 °C – 40 °C 20 °C
T-REDUCED *) 5 °C – 40 °C 10 °C
T-ABSENCE 5 °C – 40 °C 15 °C
T-LIMIT DAY ----, (-5) °C – 40 °C 19 °C
T-LIMIT N ----, (-5)°C – 40 °C 10 °C
HEATSLOPE 0,00 – 3,00 1,20
ADAPTION 00, 01 (OFF/ON) 00 = OFF
ROOM INFL ----, 00 – 20 10
T-ROOM ADJ (-5.0) K – (5.0) K 0,0 K
OPT HEAT UP 00, 01, 02 00
MAX OPT-TIME 0:00 – 3:00 [h] 2:00 [h]
OPT REDUCED 0:00 – 2:00 [h] 0:00 [h]
PC-ENABLE 0000 – 9999 0000
RETURN Exit level using Ä
