10 Settings
Pos: 70.2 /BA/Sic herheit/7. Gefahrenhin weise alt/Mähwerke/G efahr - Reparatur_W artung_Reinigungs_3 @ 0\ mod_1196660613260_78. docx @ 9153 @ @ 1
Danger! - When performing repair, maintenance or cleaning work on the machine , or in
the case of technical intervention, drive elements may start moving.
Effect: Danger to life, injuries or damage to the machine.
• Switch off the engine and remove the ignition key.
• Secure the machine against accidental start-up and against rolling!
• The cutter blades can continue to rotate after the drive has been switched off. Only
approach the machine once the work tools have come to a complete standstill!
• After completing maintenance work reattach all safety devices properly.
• Avoid skin contact with oil and grease.
• Seek medical help immediately should injuries caused by oil escaping under pressure
occur.
Pos: 70.3 /Überschri ften/Überschri ften 2/A-E/Einstellu ng der Entlastungsfeder n @ 0\mod_1196666659447_7 8.docx @ 10133 @ 2 @ 1
10.1 Adjusting the Compensation Springs
Pos: 70.4 /BA/Sic herheit/7. Gefahrenhin weise alt/Mähwerke/ Gefahr - Einstellung an den En tlastungsfeder n @ 0\mod_1196751594562_78. docx @ 12575 @ @ 1
Danger! - Setting on the compensation springs
Effect: Danger to life or serious injuries
• The compensation springs must only be removed in transport position. In the working
position the compensation springs are subject to high tensile stress.
• Severe injury can be caused if the compensation springs are removed while in the working
position.
• The lower threaded blocks on the compensation springs must be fully screwed in.
Pos: 70.5 /BA/Einste llungen/Mähwerke/Easy Cut/Bodendruc k/Bodendruck allge meiner Text alle EC @ 0\mod_119666 7271181_78.doc x @ 10190 @ @ 1
The ground pressure for the cutter bar is adjusted to local conditions by means of the
compensation springs. In order to protect the sward the load on the mowing spar must be
relieved so that it does not jump when mowing, yet does not leave any skid marks on the
ground.
