Krone EasyCut F 360 - Lower Suspension Arm

Start-up
38
Pos: 94.12.1 /Üb erschriften/Üb erschriften 3/U-Z/U nterlenkera dapter @ 79\m od_13146887 43340_78.doc x @ 697532 @ 3 @ 1
7.2.1 Lower suspension arm
Pos: 94.12.2 /B A/Inbetriebnahm e/EasyCut/U nterlenkeradapter /Unterlenkerad apter fixieren Bild @ 79\m od_131469033890 0_78.docx @ 697669 @ @ 1
Fig.
15
Pos: 94.12.3 /B A/Inbetriebnahm e/EasyCut/U nterlenkeradapter /Unterlenkerad apter fixieren / pendelnd Einführt ext @ 136\ mod_1352380 302114_78.doc x @ 1208499 @ @ 1
The lower suspension arm adapters (1) serve as extension to increase the distance of the
machine to the front wheels of the tractor.
On tractors with floating (height movable) lower links, the lower suspension arm adapters must
be fastened.
On tractors with rigid lower links, the lower suspension arm adapters must be set floating.
Pos: 94.12.4 /B A/Inbetriebnahm e/EasyCut/U nterlenkeradapter /Unterlenkerad apter fixieren @ 136\mod_1 352380102898_ 78.docx @ 1 208413 @ @ 1
Fastening the Lower Suspension Arm Adapters
To do this:
• Connect the machine to the Weiste triangle.
• Lower the machine into working position.
• Move the front power lift into float position.
• Turn off the engine, remove the ignition key and secure the tractor and the machine against
accidental start-up and against rolling.
• Turn out screw (2) until the bolt (A) of the lower suspension arm adapter (1) touches the
stop (B) of the Weiste triangle (right and left machine side).
• Lock the screw (2) with nut (3).
Pos: 94.12.5 /B A/Inbetriebnahm e/EasyCut/U nterlenkeradapter /Unterlenkerad apter pendeln d einstellen @ 136\ mod_135 2380217006_78 .docx @ 1208 442 @ @ 1
Setting the Lower Suspension Arm Adapters Floating
To do this:
• Connect the machine to the Weiste triangle.
• Lower the machine into working position.
• Move the front power lift into float position.
• Turn off the engine, remove the ignition key and secure the tractor and the machine against
accidental start-up and against rolling.
• Screw in screw (2) completely.
• Lock the screw (2) with nut (3).
