Maintenance – lubrication chart
82
Pos: 139.1 /Übersc hriften/Überschrif ten 1/U-Z/ Wartung - Sc hmierplan @ 0\ mod_1197359 304198_78.docx @ 18232 @ 1 @ 1
14 Maintenance – lubrication chart
Pos: 139.2 /Übersc hriften/Überschrif ten 2/P-T/S Spezielle Sic herheitshinw eise @ 0\mod_11 96660495760_ 78.docx @ 9 134 @ 2 @ 1
14.1 Special Safety Instructions
Pos: 139.3 /BA/Sic herheit/7. G efahrenhinweise alt/Mähwerke/ Warnung - R eparatur_Wartu ng_Reinigungs_ 4 allgemein Eas yCut @ 292\ mod_14109414 23112_78.doc x @ 2299026 @ @ 1
WARNING!
When performing repair, maintenance or cleaning work or in case of technical
intervention, drive elements may start moving (caution: cutting discs continue to run).
Effect: Danger to life, injuries or damage to the machine.
• Turn off the PTO shaft.
• Move the machine to the working position and lower it to the ground.
• Switch off the engine of the tractor, remove the ignition key and carry it with you.
• Secure the tractor against accidental start-up and against rolling.
• After the repair, maintenance, cleaning work or technical modifications are completed,
mount all protective covers and safety devices properly again.
• Avoid skin contact with oils, greases, cleaning agents and solvents.
• In the event of injuries or burns due to oils, cleaning agents or solvents, contact a physician
immediately.
• All other safety instructions must also be followed to avoid injuries and accidents.
Pos: 139.4 /BA/ Wartung/Gelen kwelle schmiere n/Abschmieren Gelenkwelle Bil d 100 h Bild 250 h @ 163\ mod_1366120 237972_78.docx @ 1426505 @ @ 1
Fig.
Pos: 139.5 /BA/ Wartung/Gelen kwelle schmiere n/Abschmieren Gelenkwell e Text @ 16\ mod_1235638171 674_78.doc x @ 199556 @ @ 1
Lubricate the PTO shafts at the intervals indicated in the drawing with a multi-purpose grease.
Follow the operating instructions of the PTO shaft manufacturer.
