Krone EasyCut F 360 - Installation of Weiste Triangle; Preparation on the Front-Mounted Disc Mower

Commissioning
34
Pos: 92.13 /BA/Ers tinbetriebna hme/EasyCut/Anb au Weiste-Drei eck @ 3\m od_12046408903 45_78.docx @ 71160 @ 2 @ 1
6.4 Installation of Weiste triangle
1
Fig.
10
Pos: 92.14 /BA/Sic herheit/7. G efahrenhinweise alt/Mähwerke/ Warnung Anb au des Kuppeldrei ecks (Weiste Dr eieck) @ 3\ mod_12046383 78407_78.doc x @ 71102 @ @ 1
Warning - Installation of the triangle linkage (Weiste triangle)
Effect: Danger to life or serious injuries. Considerable damage to the machine
Observe manufacturer's operating instructions for the triangle linkage!
Pos: 92.15 /BA/Ers tinbetriebna hme/EasyCut/Anb au Weiste-Drei eck Text @ 3 \mod_120463 8631735_78. docx @ 71179 @ @ 1
For the installation of the front-mounted disc mower, a Weiste triangle (1) is attached to the front
hydraulics. Adjust the top suspension arm in such a way that the triangle is inclined slightly
forward.
Pos: 92.16 /Übersc hriften/Überschrif ten 2/U-Z/ VVorbereitung am Frontscheib enmäher @ 3 5\mod_12574 97246000_78.d ocx @ 329285 @ 2 @ 1
6.5 Preparation on the front-mounted disc mower
Pos: 92.17 /BA/Ers tinbetriebna hme/EasyCut/Vor bereitung am Fr ontscheiben mäher EC 28/32 28P/32P 2 8M @ 10\mod_ 1221659810103 _78.docx @ 1 36162 @ @ 1
Fig.
11
:
• Push the PTO shaft (3) with full protection (4) onto the PTO shaft end of the machine.
• The safety mechanism must engage
• Secure the PTO shaft guard (2) against turning with pipe clamp (2).
