Start-up
41
Pos: 94.25 /Übersc hriften/Überschrif ten 2/F-J /GGelenkwelle montieren @ 2\mod_1202398 342788_78.doc x @ 59253 @ 2 @ 1
7.5 Install the PTO shaft
Pos: 94.26 /BA/I nbetriebnahme/ EasyCut/Anbau Gelenkwelle/ Anbau Gelen kwelle @ 3\m od_1204702102 883_78.docx @ 71462 @ @ 1
2
1
Fig.
18
Swivel the PTO shaft bracket under the Weiste triangle
Push the PTO shaft (1) onto the front PTO shaft of the tractor and secure
Secure the PTO shaft guard against turning with the retaining chain (2).
Pos: 94.27 /La yout Module /---------------Seitenumbruch---------------- @ 0\ mod_11961 75311226_0.doc x @ 4165 @ @ 1
