Start-up
40
Pos: 94.19 /Übersc hriften/Überschrif ten 2/F-J /GGelenkwelle @ 0\mod_119 9781879794_78.d ocx @ 3454 2 @ 2 @ 1
7.4 PTO shaft
Pos: 94.20 /BA/Sic herheit/Gele nkwelle/Gefahr - Sich drehend e Gelenkwelle_ 2 @ 0\mod _119978169295 0_78.docx @ 34 523 @ @ 1
Danger! - Rotating PTO shaft
Effect: Danger to life or serious injuries
• Install or detach the PTO shaft only with the engine switched off and the ignition key
removed.
• Secure the tractor against rolling.
• Make sure that the PTO shaft is coupled properly (the lock of the PTO shaft must have
snapped in).
• Make sure that the protective devices are attached properly.
• Never use a PTO shaft, the protective devices of which have not been attached.
• Replace damaged protective devices immediately
• Attach the safety chain of the PTO shaft so that the guard tube does not rotate
simultaneously with the PTO shaft.
Pos: 94.21 /BA/Sic herheit/Gele nkwelle/Gefahr - Antriebsdr ehzahl 1000 beach ten @ 3\m od_1204700292 070_78.doc x @ 71424 @ @ 1
Danger! - Observe drive speed
Effect: Danger to life or serious injuries
• This machine is driven at a maximum PTO speed of 1000 rpm.
Pos: 94.22 /Übersc hriften/Überschrif ten 3/K-O/ LLängenanpas sung @ 1\ mod_12016876328 10_78.docx @ 53589 @ 3 @ 1
7.4.1 Length adjustment
Pos: 94.23 /BA/Ers tinbetriebna hme/Gelenkwelle/M ähwerke/Lä ngenanpassung G elenkwelle EC 32CVF @ 3\ mod_120470 1667336_78.doc x @ 71443 @ @ 1
Fig.
• Hold the two PTO shaft halves (1) and (2) next to each other
• Check the cover of the special section tubes and guard tubes
• Shorten special section tubes and guard tubes until they can move freely in any operating
position
• For detailed information on adjusting the length, please refer to the operating instructions of
the PTO shaft manufacturer
