Krone EasyCut F 360 - Detaching the Machine; Removing the Compensation Spring(S)

Operation
50
Pos: 98.12 /Übersc hriften/Überschrif ten 2/A-E/ AAbbau der Mas chine @ 3\m od_120479238 7824_78.docx @ 73245 @ 2 @ 1
9.3 Detaching the machine
Pos: 98.13 /BA/Sic herheit/Eas yCut/Gefahr - M aschine abstell en_ohne Hydra ulikschlauch @ 3\mod_1204 793072152_78.d ocx @ 7328 3 @ @ 1
Danger! - Unexpected movements of the machine
Effect: Danger to life, serious injuries
• No one is permitted inside the danger zone.
• Park the machine on a solid and even surface.
• You should not unhitch the machine until the engine has been switched off and the ignition
key has been removed.
• Secure the tractor against rolling.
• Use extreme caution when attaching implements to or detaching them from the tractor! The
accident prevention regulations must be complied with absolutely.
• When detaching the machine, do not walk between the tractor and the machine!
Pos: 98.14 /Übersc hriften/Überschrif ten 2/A-E/DD emontage d er Entlastungsf eder (n) @ 3\ mod_120479 2429324_78.doc x @ 73264 @ 2 @ 1
9.4 Removing the compensation spring(s)
Pos: 98.15 /BA/Sic herheit/7. G efahrenhinweise alt/Mähwerke/G efahr - Einst ellung an den E ntlastungsfeder n @ 0\mod_11 96751594562 _78.docx @ 12575 @ @ 1
Danger! - Setting on the compensation springs
Effect: Danger to life or serious injuries
• The compensation springs must only be removed in transport position. In the working
position the compensation springs are subject to high tensile stress.
• Severe injury can be caused if the compensation springs are removed while in the working
position.
• The lower threaded blocks on the compensation springs must be fully screwed in.
Pos: 98.16 /BA/Be dienung /Eas yCut/Weiste-D reieck/Abbau W eiste-Dreiec k Bild EC 28/32 @ 10\mod_12 21736766364 _78.docx @ 13675 2 @ @ 1
4
3
2
1
Fig.
25
Pos: 98.17 /BA/Be dienung /Eas yCut/Weiste-D reieck/Abbau W eiste-Dreiec k Text EC 28/3 2 28/32CV @ 1 0\mod_12217 36705176_78.d ocx @ 136733 @ @ 1
• Bring the front mowing unit into the transport position.
• Remove compensation spring (2) and hang it on hook (1).
• Lower front-mounted disc mower.
• Pull spring cotter pin (5) out of the Weiste triangle.
• Release the interlock of the holding triangle.
• Loosen the guard cloth.
• Remove the retaining chain (4) of the PTO shaft (3).
• Remove the PTO shaft (3) from the tractor side and place on the PTO shaft bracket
• Carefully lower the front hydraulics.
• Drive carefully out of the holder of the front-mounted disc mower.
