12.5 Oil level check and oil change on the cutter bar
Pos: 133.2 /Übersc hriften/Überschrif ten 3/K-O/ OÖlwechsel @ 0\mod_119 7021941955_78 .docx @ 16139 @ 3 @ 1
12.5.1 Oil change
Pos: 133.3 /BA/ Wartung/Mähw erke/Hinweis Ein Ölwechsel a m Mähholm ist nic ht erforderlich. @ 68\mod _130457739138 8_78.docx @ 62 8708 @ @ 1
Note
No oil change is required on the cutter bar.
Pos: 133.4 /Übersc hriften/Überschrif ten 3/K-O/ OÖlkontrolle @ 0\mod_1197 021908190_7 8.docx @ 16120 @ 3 @ 1
12.5.2 Checking the oil level
Pos: 133.5 /BA/Sic herheit/7. G efahrenhinweise alt/Mähwerke/G efahr - Sch nell rotierende M esserteller/M essertrommel_2 @ 0\mod_1197 022569252_7 8.docx @ 1616 5 @ @ 1
Danger! - Rapidly rotating cutting discs/blade drums.
Effect: Danger to life or serious injuries.
Lower guards. Nobody should be in the danger zone around the machine.
Pos: 133.6 /BA/Sic herheit/7. G efahrenhinweise alt/Mähwer ke/Gefahr - Sch nell rotierende M esserteller/M essertrommeln_1 @ 0\mod_119 7017696736_ 78.docx @ 1600 1 @ @ 1
Danger! - Rapidly rotating cutting discs/blade drums.
Effect: Danger to life or serious injuries.
• Switch off the engine and remove the ignition key.
• The cutting discs/blade drums continue to run!
• Do not leave the driver’s cab until the cutting discs/blade drums have come to a complete
stop.
Pos: 133.7 /Übersc hriften/Überschrif ten 3/K-O/MM ähhol m ausrichten @ 0\m od_11970179 56815_78.doc x @ 16042 @ 3 @ 1
12.5.3 Aligning the Cutter Bar
Pos: 133.8 /BA/ Wartung/Mähw erke/Mähholm ausrichten EasyC ut @ 3\mo d_12047218036 48_78.docx @ 7 2358 @ @ 1
Fig.
38
Oil level check
• Align the cutter bar using a spirit level (1).
Crosswise
• Lay the spirit level on top of the cutting disc hub parallel to the direction of travel.
Lengthwise
• Lay the spirit level (1) on top of two mower discs.
