Krone EasyCut F 360 - After Shearing off

Maintenance
64
Pos: 105.16 /BA /Wartung/Mäh werke/Schersic herungNach de m Abscheren E asyCut @ 364\ mod_144050 1433026_78.doc x @ 2678607 @ 3 @ 1
11.5.2 After Shearing Off
Caution! - Correct installation position of the bearing housing not observed.
Effect: Damage to the machine
• Right rotating (RE/RZ) cutting discs and drums always have right-handed pinion shafts and
nuts (no groove mark on the pinion shaft and nut).
• Left rotating (LE/LZ) cutting discs and drums always have left-handed pinion shafts and nuts
(with groove mark on the pinion shaft and nut).
1
3
2
8
7
3
4
c
d
a
9
b
EC-255-1
10
3a
3a
3a
Fig.
32
