Krone EasyCut R 360 User Manual

Operation
38
Pos: 66.17 /Übersc hriften/Überschri ften 2/K-O/Mähwerk abkl appen @ 207\mod_138667335 6360_78.docx @ 1713738 @ 2 @ 1
10.3 Folding Down Mowing Unit
Pos: 66.18 /BA/Sic herheit/7. Gefahrenhin weise alt/Mähwerke/ Gefahr - Absenken des Mäh werks in Arbeitsstell ung EC 280/320 @ 9\mod_122087 9244798_78.doc x @ 128439 @ @ 1
Danger! - Lowering the mowing unit into the working position
Effect: Danger to life, injuries or damage to the machine.
• Lower the mowing unit only when you are absolutely sure that neither persons, animals nor
objects are in the swivel range of the mowing unit.
• Switch on the PTO only when the mowing unit is resting on the ground.
Pos: 66.19 /Übersc hriften/Überschri ften 3/U-Z/Von Transport- in Vorgewendestell ung @ 202\mod_13859673808 99_78.docx @ 1694554 @ 3 @ 1
10.3.1 From Transport Position to Headland Position
Pos: 66.20 /BA/Sic herheit/7. Gefahrenhin weise alt/Mähwerke/ Gefahr - Absenken des Mäh werks in Arbeitsstell ung EC 280/320 @ 9\mod_122087 9244798_78.doc x @ 128439 @ @ 1
Danger! - Lowering the mowing unit into the working position
Effect: Danger to life, injuries or damage to the machine.
• Lower the mowing unit only when you are absolutely sure that neither persons, animals nor
objects are in the swivel range of the mowing unit.
• Switch on the PTO only when the mowing unit is resting on the ground.
Pos: 66.21 /BA/Bedienun g /EasyCut/Heck/ Von Transport in Vorgewende stellung EasyCut R 280/ 320 CV(CR) @ 207\mod_1386 673626623_78.docx @ 17137 67 @ @ 1
From transport position to headland position
• Activate the double-action control unit (red 2/blue 2) until the mowing unit is lowered into
headland position.
Pos: 66.22 /Übersc hriften/Überschri ften 3/U-Z/Vorgewende stellung @ 202\mod_13859 67558108_78.doc x @ 1694612 @ 3 @ 1
10.3.2 Headland Position
Pos: 66.23 /BA/Sic herheit/Vorgewendeste llung/Gefahr - Vorgewende Mähwerke EC 280/320 CV- Q @ 10\mod_122154465438 5_78.docx @ 134415 @ @ 1
Danger! - Lifting the mowing unit from the working position into headland position
Effect: Danger to life, injuries or damage to the machine.
• Lift the mowing unit into headland position only when you are absolutely sure that neither
persons, animals nor objects are in the swivel range of the mowing unit.
Pos: 66.24 /BA/Bedienun g /EasyCut/Heck/ Vorgewendestellung Easy Cut R 280/320 CV(CR) @ 207\ mod_1386673852647_78. docx @ 1713795 @ @ 1
Prerequisite:
– The mowing unit is in headland position.
Lowering the mowing unit from headland position to working position
• Move the single-action control unit (red 1) to float position until the mowing unit is lowered
into working position.
Moving the mowing unit from working position to headland position
• Activate the single-action control unit (red 1) until the mowing unit is raised into headland
position.
Pos: 66.25 /Übersc hriften/Überschri ften 3/U-Z/Von Vorgewend e- in Transportstell ung @ 202\mod_13859676437 43_78.docx @ 1694670 @ 3 @ 1
10.3.3 From Headland Position to Transport Position
Pos: 66.26 /BA/Bedienun g /EasyCut/Heck/ Von Vorgewende- in Transpor tstellung bringen Te xt EasyCut R 280/320 CV(CR) @ 207\mod_1386743092258_ 78.docx @ 1714897 @ @ 1
Prerequisite:
– The PTO shaft drive is turned off.
– The parking supports are swivelled into transport position and locked by bolts, refer to
chapter Start-up “Swivelling Parking Support into Transport Position”.
– The machine is in headland position.
From headland position to transport position:
• Activate the double-action control unit (red 2 / blue 2) until the mowing unit is raised from
headland position to transport position.
Pos: 66.27 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0. docx @ 4165 @ @ 1
