Maintenance - Gearbox
57
Pos: 76.11 /BA/W artung/Ölkontrolle_Wec hsel/Ölwechsel_AL T/Schutz (4) demontieren @ 58\mod_12967353962 86_78.docx @ 553788 @ @ 1
• Remove the guard (4)
Pos: 76.12 /BA/W artung/Ölkontrolle_Wec hselÖlwechsel NEU @ 140\m od_1355142057277_7 8.docx @ 1244610 @ @ 1
Oil change:
Collect escaping oil in a suitable container.
• Screw out oil drain plug and drain the oil.
• Screw out inspection screw and filler plug.
• Screw in oil drain plug and tighten it securely.
• Top up new oil via oil filling hole until the control hole is reached.
• Screw in the inspection screw and the filler plug and tighten them securely.
Pos: 76.13 /BA/W artung/Ölkontrolle_Wec hsel/Ölwechsel_AL T/Schutz (4) montieren @ 58\mod_1296735440474 _78.docx @ 553814 @ @ 1
• Install the guard (4)
Pos: 76.14 /BA/W artung/Ölkontrolle_Wec hsel/Hinweis - Altöl ordn ungsgemäß entsorgen @ 0\ mod_1197008117002_78. docx @ 15550 @ @ 1
Note
The used oil must be disposed of correctly
