INFORMATION ABOUT THIS DOCUMENT
10
Operating instructions • Semitrailer • 505369471-04 • 02/2019
The type plate is attached to the following
location for product identification:
L:
Typ
mm
kg
kg
kg
kg
1-
Fahrzeugwerk Bernard Krone GmbH & Co. KG
2-
3-
kg
kg
kg
kg
kg
1-
2-
3-
kg
W: mm
b/b
MAX : mm
b
MIN : mm
Fig.1-1: Type plate attachment points
1 Standard
2 Alternative
The following information is shown on the
type plate:
Fig.1-2: Example type plate
1 Manufacturer
2 EC type approval number (if available)
3 Vehicle ID number
4 Approved total mass
5 Total mass on the coupling point
6 Total mass of the axles
7 Technically approved total mass
8 If applicable, the nationally approved
total masses for registration/operation
including the code
9 If applicable, dead weight
10 Min. distance
11 Distance/max. distance
12 Vehicle width
13 Vehicle length
14 If applicable, national type approval no.
15 Type designation
1.4 Retention of documents
► Store these instructions and all other
applicable documents in a safe place.
► Pass the complete documentation on
to the next driver or owner.
1.5 Part positions
The description of part positions is always
viewed in forward driving direction.
1.6 Optional components
KRONE trailers are fitted with a number of
optional components. The operating in-
structions describe all of the components in
the following sections.
All the components are not necessarily on
your trailer.
1.7 Symbols used in these in-
structions
Various markings and symbols are used in
the text in these instructions. These are ex-
plained below.
○ Bullet list
– Sub-list
1. Numbered list
þ Prerequisite for action
► Action step
ð Intermediate action result
ü Result of the action
INFO
Additional information and tips.
: Also observe the enclosed supplier
documentation.
1.8 Copyright
These instructions represent an official
document within the meaning of laws
against unfair competition. They incorpor-
