Krone Profi Liner - Mud flap; Spare wheel bracket

RUNNING GEAR OPERATION
56
Operating instructions • Semitrailer • 505369471-04 • 02/2019
5.17 Mud flap
The mudguards of KRONE trailers that are
designed for rail loading can be equipped
with fold-up mud flaps on both sides.
Folding up the mud flap
1
3
2
4
Fig.5-45: Folded down mud flap
1 Mudguard
2 Hook
3 Hooking eyelet
4 Mud flap
► Fold up the mud flap.
► Attach the hooking eyelet to the hook
on the mudguard.
ü The mud flap is folded up.
Folding down the mud flap
► Unhook the hooking eyelet from the
hook on the mudguard.
► Fold down the mud flap.
ü The mud flap is folded down.
5.18 Spare wheel bracket
!
WARNING
Risk of accident from an unsecured
spare wheel!
An unsecured spare wheel can fall off
when driving and cause serious accidents.
► Properly secure the spare wheel.
► Only transport wheels that are de-
signed for the spare wheel bracket.
► Check the spare wheel bracket for
damage.
► Immediately repair the spare wheel
bracket if defective.
CAUTION
Risk of injury due to a falling spare
wheel!
The weight of a falling spare wheel can
cause injuries.
► Work carefully when changing a spare
wheel.
KRONE trailers can be equipped with a
spare wheel bracket. Depending on the
equipment, the following versions are pos-
sible:
○ Spare wheel with basket storage (see
"5.18.1 Spare wheel with basket storage",
pg.57)
○ Spare wheel with winch (see "5.18.2
Spare wheel with winch", pg.57)
○ Spare wheel in the pallet storage box
(see "5.18.3 Spare wheel in the pallet stor-
age box", pg.58)
