SUPERSTRUCTURE OPERATION
84
Operating instructions • Semitrailer • 505369471-04 • 02/2019
6.2.6 Curtain rope bracket
!
WARNING
Risk of accident due to curtain rope
flapping around!
Unsecured excess curtain rope can flap
around and injure other road users or
cause damage to the vehicle.
► Prevent excess curtain rope from flap-
ping around.
► Use the curtain rope bracket (if avail-
able).
1 2
Fig.6-33: Curtain rope bracket
1 Curtain rope bracket
2 Front wall
Securing the curtain rope on the curtain
rope bracket
► Wind the curtain rope on the curtain
rope bracket.
► Slide the end of the rope into the
wound-up curtain rope.
ü The excess curtain rope is secured on
the curtain rope bracket.
Releasing the curtain rope from the cur-
tain rope bracket
► Pull the end of the rope out of the
wound-up curtain rope.
► Unwind the curtain rope.
ü The curtain rope is released from the
curtain rope bracket.
6.2.7 Comfort equipment
1
2
5
4
3
Fig.6-34: Comfort curtain (interior view)
1 Corner post
2 Cable
3 Bungee cord
4 Lock for closed curtain
5 Curtain package arrester
Opening the side curtain
► Open all the curtain buckles (see "6.2.2
Curtain buckle", pg.75).
1
2
Fig.6-35: Curtain buckle
1 Belt
2 Wire hook
► Bring the end of the belt behind the
wire hook of the curtain buckle. This
prevents the wire hook from getting
caught onto the side curtain during the
lifting procedure.
