SUPERSTRUCTURE OPERATION
Operating instructions • Semitrailer • 505369471-04 • 02/2019
85
► If necessary, open the side curtain at
the front (see "6.2.4 Front curtain tension-
ing device", pg.78) and at (see "6.2.5
Rear curtain tensioning device", pg.82) the
rear.
► Fold down the opened side curtain and
affix them with the bungee cord.
1
2
3
Fig.6-36: Loosening the lock with the cable
1 Cable
2 Bungee cord
3 Lock for closed curtain
► Loosen the lock with the cable.
► Pull open the side curtain.
1
Fig.6-37: Curtain package arrester
1 Locking lever
► Fold down the locking lever of the cur-
tain package arrester to keep the cur-
tain in the open position.
ü The side curtain is open.
Closing the side curtain
► Fold up the locking lever of the curtain
package arrester to release the side
curtains held in position.
► Pull the side curtain closed until the
lock engages.
► Close the side curtains at the front (see
"6.2.4 Front curtain tensioning device",
pg.78) and rear (see "6.2.5 Rear curtain
tensioning device", pg.82).
► Close all curtain buckles (see "6.2.2 Cur-
tain buckle", pg.75).
ü The side curtain is closed.
Lifting the roof
!
WARNING
Risk of accident due to failure to re-
move rearward load securing!
If the rearward load securing is not re-
moved before lifting the roof, the load se-
curing system can fall over, injure people,
and damage the trailer.
► Always remove the rearward load se-
curing before lifting the roof.
þ The rearward load securing is re-
moved (see "" pg.88).
► Open the rear doors and secure them
with the Door Fix (see "6.1.3 Door stop
and Door Fix", pg.68).
► Open all the curtain buckles (see "6.2.2
Curtain buckle", pg.75).
