RUNNING GEAR OPERATION
50
Operating instructions • Semitrailer • 505369471-04 • 02/2019
5.13.4 Fold-down steps
KRONE trailers with a folding rear wall and
folding side walls can be equipped with
fold-down steps.
1
Fig.5-34: Fold-down steps on the folding
rear wall
1 Fold-down steps
► Fold out the fold-down steps before
use.
► Use hand straps for mounting and dis-
mounting (see "5.13.1 Hand strap",
pg.48).
► Fold in the fold-down steps again after
use.
5.14 Rear underrun protection
KRONE trailers can be equipped with the
following versions of the movable underrun
protection:
○ Fold-up rear underrun protection (see
"5.14.1 Fold-up rear underrun protection",
pg.50)
○ Rear underrun protection that swivels
on both sides (see "5.14.2 Rear underrun
protection that swivels on both sides",
pg.51)
5.14.1 Fold-up rear underrun protec-
tion
!
WARNING
Risk of accident when driving with the
rear underrun protection folded up!
Driving with the rear underrun protection
folded up is not permitted by law. In a col-
lision, other motorists can drive under the
vehicle and be fatally injured.
► Only drive with the rear underrun pro-
tection properly folded down and
locked in place.
CAUTION
Risk of injury from the rear underrun
protection folding down unintention-
ally!
If the rear underrun protection is folded
up, but not properly secured (e.g. when
loading at a rail terminal), it can suddenly
fold down and injure people.
► Always lock the rear underrun protec-
tion.
Folding up the rear underrun protection
► Release the underrun protection lock.
1
2
3
Fig.5-35: Underrun protection lock
1 Underrun protection lock
2 Rear underrun protection
3 Spring latch
