Krone Profi Liner - Using the Multi Flex Chain Adapter; Using the Multi Flex Flat Chain Adapter

LOADING AND SECURING
Operating instructions • Semitrailer • 505369471-04 • 02/2019
139
The Multi Lash lashing rings can be flexibly
screwed into the existing holes in the Multi-
lock external frame (see "8.9.1 Using the
Multi-Lock external frame", pg.138). Multi Lash
can support loads up to 2,000daN.
8.9.3 Using the Multi Flex chain ad-
apter
KRONE trailers can be equipped with Multi
Flex chain adapters. The chain adapter en-
ables the use of many different hook
shapes on the lashing belts and lashing
chains.
Fig.8-10: Multi Flex chain adapter with Mul-
tilock external frame
The Multi Flex chain adapter is locked with
two hooks onto the Multi Lock external
frame (see "8.9.1 Using the Multi-Lock external
frame", pg.138). It can sustain loads up to
4,000 daN.
Inserting the Multi Flex chain adapter
2
1
Fig.8-11: Multi Flex chain adapter
1 Hook mount
2 Hook for Multi Flex chain adapter
► Attach the hook for the Multi Flex chain
adapter to the lashing holes on the
Multilock external frame.
► Attach the lashing belt hook to the
hook mount of the Multi Flex chain ad-
apter.
ü The Multi Flex chain adapter has been
inserted.
8.9.4 Using the Multi Flex Flat chain
adapter
KRONE trailers can be equipped with Multi
Flex Flat chain adapters. A chain adapter
for flat lashing allows the tension straps to
be attached above the Multi Lock external
frame (see "8.9.1 Using the Multi-Lock external
