16.2 Chain for height restriction of suspension arms

Figure 77

• Secure chains (1) with a spring-type slotted straight pin (3) and a washer (2) at the

suspension arm seats.

• Attach chain hooks (4) to the tractor.

• Select chain length according to desired max. lowering level.

Note

Spare tine loss safeguards Order No. : 153 479 0

Chain for height restriction of suspension arms Order No.: 250 759 0
