10 TUNING THE CHASSIS 123
B00573-10
– Turn adjusting screws 1 clockwise to the stop.
Info
The adjustment screws are located at the top end of the fork legs.
Make the same adjustment on both fork legs.
– Turn counterclockwise by the number of clicks corresponding to the fork type.
Guideline
Rebound damping
Comfort 20 clicks
Standard 20 clicks
Sport 10 clicks
Full payload 10 clicks
Info
Turn clockwise to increase suspension damping; turn counterclockwise to reduce
damping.
10.4 Adjusting the spring preload of the fork
Info
Spring preload determines the initial fork position.
The best spring preload setting is achieved when it is set for the weight of the rider and that of any baggage and a passenger, thus
ensuring an ideal compromise between maneuverability and stability.
