17 SERVICE WORK ON THE ENGINE 223
17.5 Installing the oil filter x
100776-10
– Insert oil filter 1.
– Lubricate the O-ring of the oil filter cover. Mount oil filter cover 2.
– Mount and tighten the screws.
Guideline
Remaining engine screws M5 6 Nm (4.4 lbf ft)
17.6 Filling up with engine oil x
Info
Too little engine oil or poor-quality engine oil results in premature wear to the engine.
B01336-10
Main work
– The oil must be topped up in two steps.
Engine oil 3.60 l (3.8 qt.) External
temperature:
≥ 0 °C (≥ 32 °F)
Engine oil
(SAE 10W/50)
( p. 258)
External
temperature:
< 0 °C (< 32 °F)
Engine oil (SAE
5W/40) ( p. 258)
– Remove the dipstick 1 and top up the engine oil.
