11 SERVICE WORK ON THE CHASSIS 156
11.1 Raising the rear of the motorcycle with lifting gear
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
B01321-01
– Insert the adapter into the lifting gear at the rear.
Adapter (61029055120)
Rear wheel stand (61029055400)
– Stand the motorcycle upright, align the lifting gear to the link fork and the adapters,
and raise the motorcycle.
11.2 Removing the rear of motorcycle from the lifting gear
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
– Secure the motorcycle against falling over.
– Remove the lift stand from the rear and lean the vehicle on the side stand.
