6 CONTROLS 31
6.11.4 Display
401121-12
The tachometer 1 displays the engine speed in revolutions per minute (RPM).
The red marking 2 marks the over-rev (excessive speed) range of the engine.
The gear display 3 shows the engaged gear.
Info
The engaged gear can also be displayed in the info display.
The speed 4 is displayed in kilometers per hour KM/H or in miles per hour MPH.
The time appears in segment 5.
Info
After reconnecting the battery or changing the fuse, the time must be reset.
The coolant temperature is shown in degrees Celsius or Fahrenheit in segment 6.
The info display 7 shows additional information.
