10 TUNING THE CHASSIS 134
10.14 Adjusting the vehicle level at the rear
Warning
Danger of accidents Modifications to the suspension settings can seriously alter the vehicle's ride behavior.
– Following modifications, ride slowly at first to get the feel of the new ride behavior.
100696-10
– Loosen screw 1.
100697-10
– Turn eccentric shaft 2 to the desired position using the tool from the tool set.
Guideline
Standard LOW
Maximum adjustment range between
HIGH - LOW
180°
Open end wrench SW 38 (69012021000)
Info
The chassis height can be adjusted in both directions.
