20 TROUBLESHOOTING 232
Faults Possible cause Action
Engine doesn't crank when the electric
starter button is pressed
Operating error – Carry out the start procedure. ( p. 108)
Battery discharged –
Recharge the battery. x ( p. 194)
–
Check closed-circuit current. x
Fuse 1 or 6 is blown – Change the fuses of individual power consumers.
( p. 199)
Main fuse blown – Change the main fuse. ( p. 197)
Ignition/steering lock or emergency
OFF switch defective
–
Check the ignition/steering lock. x
–
Check the emergency OFF switch. x
Safety start system defective – Read out the trouble code memory using the
KTM diagnostics tool. x
Immobilizer active – Read the immobilizer blink code.
EFI control unit not activated –
Encode the EFI control unit. x
Malfunction in CAN bus communica-
tion
– Read out the trouble code memory using the
KTM diagnostics tool. x
Combination instrument defective –
Check the combination instrument. x
Engine cranks only if the clutch lever
is pulled
A gear is engaged – Shift into neutral.
Safety start system defective – Read out the trouble code memory using the
KTM diagnostics tool. x
Engine cranks although it is in gear Safety start system defective – Read out the trouble code memory using the
KTM diagnostics tool. x
Engine cranks but doesn't start Fuse 5 blown – Change the fuses of individual power consumers.
( p. 199)
Coupling of fuel hose connection not
joined together
– Join coupling of fuel hose connection together.
