KTM 2013 1190 RC8 R EU/UK User Manual

14 ELECTRICAL SYSTEM 202
100743-10
– Release the latch 3.
– Remove the lamp cover 4.
700295-01
– Disconnect plug-in connector 5.
– Push off the retaining clamp 6 on both sides, squeeze and fold to the side.
– Remove headlight bulb 7.
700296-01
– Position the new headlight bulb in the headlight housing.
Low beam / high beam (H7 / base PX26d) ( p. 250)
Info
Insert the headlight bulb so that the lug 8 is positioned in the cut-out.
– Position the retaining clamp.
– Position the plug-in connector.
