21 IMMOBILIZER BLINK CODE 236

Blink code of immobilizer indica-

tor lamp

21 Immobilizer indicator lamp flashes 2x short, 1 second pause, 1x short

Error level condition Immobilizer control unit not activated

Blink code of immobilizer indica-

tor lamp

31 Immobilizer indicator lamp flashes 3x short, 1 second pause, 1x short

Error level condition Malfunction, encryption query from EFI control unit to immobilizer control unit

Blink code of immobilizer indica-

tor lamp

32 Immobilizer indicator lamp flashes 3x short, 1 second pause, 2x short

Error level condition Malfunction in CAN bus communication

Blink code of immobilizer indica-

tor lamp

60 Immobilizer indicator lamp flashes 6x short

Error level condition E²PROM malfunction
