23 TECHNICAL DATA 256
Screw, connecting lever, shock absorber
deflector
M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, engine bearer M10 45 Nm (33.2 lbf ft) –
Screw, shock absorber M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, side stand M10 35 Nm (25.8 lbf ft)
Loctite
®
243™
Rear sprocket bolt M10x1.25 50 Nm (36.9 lbf ft)
Loctite
®
243™
Screw, front brake caliper M10x1.25 45 Nm (33.2 lbf ft)
Loctite
®
243™
Nut of bell crank on frame M14x1.5 100 Nm (73.8 lbf ft) –
Lambda sensor M18x1.5 45 Nm (33.2 lbf ft) –
Nut, swingarm pivot M19x1.5 130 Nm (95.9 lbf ft) Thread greased
Screw, seat lock M22x1.5 8 Nm (5.9 lbf ft) –
Bolt, front axle M25x1.5 45 Nm (33.2 lbf ft) –
Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) Thread greased
Screw, steering head M25x1.5 18 Nm (13.3 lbf ft) –
