13.STEERING HANDLEBAR/FRONT WHEEL/FRONT BRAKE/FRONT SHOCK
ABSORBER/FRONT FORK
13-15
SUPER8 50 2T
Remove the throttle seat screw.
Remove the throttle seat from the handlebar
and disconnect the throttle cable from the
throttle pipe.
Remove the throttle pipe from the handlebar.
Remove the steering stem lock bolt, collar, nut
and the handlebar.
STEERING STEM
REMOVAL
Remove the steering stem lock nut.
Steering Stem Lock Nut Wrench
Lock Nut wrench
Screw
Nut
Special
Screws
Steering Stem Lock Nut Wrench
