8. KICK STARTER/DRIVE PULLEY/
CLUTCH/DRIVEN PULLEY
8-2
SUPER8 50 2T
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• Avoid getting grease and oil on the drive belt and pulley faces.
SPECIFICATIONS
SUPER8 50 2T
Item
Standard (mm) Service Limit (mm)
Drive pulley collar O.D.
20.01～20.025 24.24
Movable drive face I.D.
20.035～20.085 19.97
Weight roller O.D.
13.0 12.4
Clutch outer I.D.
107～107.2 107.5
Driven face spring free length
87.9 82.6
Driven face O.D.
33.965～33.985 33.94
Movable driven face I.D.
34.0～34.25 34.06
Drive belt width
18 17
TORQUE VALUES
Drive face nut 3.5～4.0kg-m
Clutch outer nut 3.5～4.5kg-m
Clutch drive plate nut 5.0～6.0kg-m
SPECIAL TOOLS
Lock nut wrench, 39mm Universal holder
Clutch spring compressor Lock nut socket wrench, 32mm
Bearing outer driver 37x40mm Bearing driver pilot, 17mm
One-way clutch puller Outer driver, 24x26mm
TROUBLESHOOTING
Poor performance at high speed or
Engine starts but motorcycle won‘t move lack of power
• Worn drive belt • Worn drive belt
• Broken ramp plate • Weak driven face spring
• Worn or damaged clutch lining • Worn weight roller
• Faulty driven face
Engine stalls or motorcycle creeps
• Broken clutch weight spring

KYMCO SUPER8 50 2T Specifications

General

Engine Type	2-stroke, single cylinder
Fuel System	Carburetor
Transmission	CVT automatic
Front Suspension	Telescopic fork
Rear Suspension	Single Shock
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Seat Height	780 mm
Ignition	CDI
Starter	Electric & Kick
Width	700 mm
Cooling System	Air-cooled
