8. KICK STARTER/DRIVE PULLEY/

CLUTCH/DRIVEN PULLEY

8-17

SUPER8 50 2T

Set the driven pulley, driven face spring and

clutch assembly onto the clutch spring

compressor. Compress the tool and install

the 28mm drive plate nut.

Tighten the 28mm nut to the specified

torque.

Torque: 5.0～6.0kg-m

CLUTCH/DRIVEN PULLEY

INSTALLATION

Install the drive belt on the clutch/driven

pulley and then install the clutch/driven

pulley onto the drive shaft.

Install the clutch outer.

Hold the clutch outer with the universal

holder.

Install and tighten the 10mm clutch outer

nut.

Torque: 3.5～4.5kg-m

Install the left crankcase cover. (

8-7)

Universal Holde

Clutch Oute

Clutch/Driven Pulley
