8. KICK STARTER/DRIVE PULLEY/

CLUTCH/DRIVEN PULLEY

8-6

SUPER8 50 2T

First install the washer and then the circlip

onto the kick starter spindle.

Install the kick lever.

LEFT CRANKCASE COVER

INSTALLATION

First install the dowel pins and then the seal

rubber.

Install the left crankcase cover and tighten

the ten bolts diagonally.

Connect the drive belt cooling air tube and

install the circlip.

Left Crankcase Cove

Seal Rubbe

Dowel Pins

Washe

Circlip

For drum brake, note the location of the

brake cable clamp and install the rear

brake cable in place with the clamp.

＊
