Maintenance
6-6 BASIC OPERATION GUIDE
Cleaning the Charger and the Registration Roller
Use the following cleaning operation whenever you replace the Toner
Container.
1
Slide the charger cleaner knob
back and forth 2 to 3 times, then
return it to its home position
(marked CLEANER HOME
POSITION).
IMPORTANT: After cleaning,
ensure the charger cleaner
returns to its home position.
If the charger cleaner is not
returned to the CLEANER HOME POSITION, a black band will appear on
subsequent copies.
2
Use the cleaning cloth supplied
with the new toner kit to wipe off
any paper dust and dirt that has
accumulated on the metal
registration roller (A) inside the
machine.
IMPORTANT: When cleaning,
avoid touching the black transfer
roller (B).
3
After cleaning, align the pins (C)
on both sides of the process unit
with the guides inside the
machine, and slide the process
unit slowly back into its original
position, until in stops.
4
Close the Front Cover.
(A)
(B)
(C)
(C)
