Misfeed in paper feeder
vertical paper convey-
ing section
The feed switch 3 (FSW3) does not turn off within speci-
fied time of its turning on (paper feed from optional cas-
sette 3).
1429 ms + Paper
length
Feed switch 3 (FSW3) does not turn off within specified
time of the paper feeder feed switch (PFFSW) turning on
(paper feed from optional cassette 4).
1064 ms
The feed switch 3 (FSW3) does not turn off within speci-
fied time of its turning on (paper feed from optional cas-
sette 4).
1064 ms
Feed switch 3 (FSW3) does not turn on within specified
time of the paper feeder feed switch (PFFSW) turning on
(paper feed from optional cassette 4).
2000 ms
20
Misfeed in MP tray
paper conveying sec-
tion
The registration switch (RSW) does not turn off within
specified time of the MP feed switch (MPFSW) turning
on.
1686 ms
The registration switch (RSW) does not turn on within
specified time of the MP feed switch (MPFSW) turning
on.
1686 ms
21
Multiple sheets in paper
feed section
The feed switch 1 (FSW1) does not turn off within speci-
fied time of its turning on (paper feed from cassette 1).
1429 ms + Paper
length
The feed switch 2 (FSW2) does not turn off within speci-
fied time of its turning on (paper feed from cassette 2).
1429 ms + Paper
length
The feed switch 3 (FSW3) does not turn off within speci-
fied time of its turning on (paper feed from optional cas-
sette 3, 4/detected by the machine).
1429 ms + Paper
length
The feed switch 3 (FSW3) does not turn off within speci-
fied time of its turning on (paper feed from optional cas-
sette 3, 4/detected by the paper feeder).
4300 ms
The feed switch 2 (FSW2) does not turn off within speci-
fied time of its turning on (paper feed from optional cas-
sette 3).
1686 ms
The paper feeder feed switch (PFFSW) does not turn off
within specified time of its turning on (paper feed from
optional cassette 4).
4300 ms
The feed switch 1 (FSW1) does not turn off within speci-
fied time of the upper paper feed clutch (PFCL-U) turning
on.
1864 ms
The feed switch 2 (FSW2) does not turn off within speci-
fied time of the lower paper feed clutch (PFCL-L) turning
on.
2121 ms
The feed switch 3 (FSW3) does not turn off within speci-
fied time of the paper feeder paper feed clutch 1
(PFPFCL1) turning on.
2036 ms
23
Multiple sheets in MP
tray conveying section
The MP feed switch (MPFSW) does not turn off within
specified time of its turning on.
1429 ms + Paper
length
Section Description Conditions Specified time
