Kyocera KM-2560

2H0/2HZ-1
1-4-22
C1030 Paper feeder lift motor 1 error
(optional paper feeder)
When optional cassette 3 is inserted,
paper feeder lift switch 1 does not turn
on within 12 s of paper feeder lift motor 1
turning on.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC22 on
the engine PWB and the connector on the
paper feeder main PWB, and the continuity
across the connector terminals. Repair or
replace if necessary.
Broken gears or
couplings of paper
feeder lift motor 1.
Replace paper feeder lift motor 1.
Defective paper
feeder lift motor 1.
Check for continuity across the coil. If none,
replace paper feeder lift motor 1.
Defective paper
feeder lift switch 1.
Check if YC1-5 on the paper feeder main
PWB goes low when paper feeder lift switch
1 is turned off. If not, replace paper feeder lift
switch 1.
C1040 Paper feeder lift motor 2 error
(optional paper feeder)
When optional cassette 4 is inserted,
paper feeder lift switch 2 does not turn
on within 12 s of paper feeder lift motor 2
turning on.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC22 on
the engine PWB and the connector on the
paper feeder main PWB, and the continuity
across the connector terminals. Repair or
replace if necessary.
Broken gears or
couplings of paper
feeder lift motor 2.
Replace paper feeder lift motor 2.
Defective paper
feeder lift motor 2.
Check for continuity across the coil. If none,
replace paper feeder lift motor 2.
Defective paper
feeder lift switch 2.
Check if YC1-7 on the paper feeder main
PWB goes low when paper feeder lift switch
2 is turned off. If not, replace paper feeder lift
switch 2.
C2000 Main motor problem
Stable OFF is detected for 1 s continu-
ously after main motor stability.
Poor contact in the
connector termi-
nals.
Check the connection of connector YC10 on
the engine PWB and the connector on the
main motor, and the continuity across the
connector terminals. Repair or replace if
necessary.
Defective drive
transmission sys-
tem.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation.
Defective main
motor.
Replace the main motor.
Code Contents
Remarks
Causes Check procedures/corrective measures
