Kyocera KM-2560

2H0/2HZ
1-5-11
18. Remove the stop ring and bush.
Figure 1-5-19
19. Remove the stop ring.
20. Raise the MP paper feed pulley shaft and
remove the MP paper feed pulley.
Figure 1-5-20
Stop ring
Bush
Stop ring
MP paper feed
pulley shaft
MP paper feed
pulley shaft
MP paper feed
pulley
