Kyocera KM-2560

2H0/2HZ
1-5-13
24. Remove the stop ring and slide the bush in
the direction of the arrow.
Figure 1-5-23
25. Slide the MP forwarding pulley shaft tempo-
rarily toward the rear side and then raise it to
remove from the MP unit.
Remove the shaft while raising the actuator
of the MP paper switch.
Figure 1-5-24
Bush
Stop ring
MP forwarding
pulley shaft
Actuator
MP unit
