Kyocera KM-2560

2H0/2HZ
1-5-31
6. Remove three screws.
7. Remove the connector.
8. Remove the toner hopper assembly.
Figure 1-5-56
9. Remove the top tray.
Figure 1-5-57
Toner hopper
assembly
Screw
Screw
Screw
Connector
Top tray
