Kyocera KM-2560

2H0/2HZ-1
1-5-48
6. Remove two tabs.
Figure 1-5-88
7. Remove the screw and rear fuser heater
cover.
8. Remove the screw and front fuser heater
cover.
9. Pull out the fuser heater.
10. Replace the fuser heater and install the
heater.
11. Refit all the removed parts.
Figure 1-5-89
Tab
Tab
Screw
Front fuser
heater cover
Fuser heater
Rear fuser
heater cover
Screw
