Kyocera KM-2560

2H0/2HZ
2-3-2
Connector Pin No. Signal I/O Voltage Description
TB
TB1 LIVE I 120 V AC
220-240 V AC
AC power input
Connected
to the AC
inlet and
main power
switch
TB2 NEUTRAL I 120 V AC
220-240 V AC
AC power input
TB3 LIVE O 120 V AC
220-240 V AC
AC power output to MSW
TB4 LIVE I 120 V AC
220-240 V AC
AC power input from MSW
YC1
1 LIVE O 120 V AC
220-240 V AC
AC power output
Connected
to the cas-
sette heater
2 N.C. - - Not used
3 N.C. - - Not used
4 NEUTRAL O 120 V AC
220-240 V AC
AC power output
YC2
1 LIVE O 120 V AC
220-240 V AC
AC power output
Connected
to the cas-
sette heater
2 N.C. - - Not used
3 N.C. - - Not used
4 NEUTRAL O 120 V AC
220-240 V AC
AC power output
YC3
1 NEUTRAL O 120/0 V AC
220-240/0 V AC
FH-M: On/Off
Connected
to the fuser
heater M/S
2 NEUTRAL O 120/0 V AC
220-240/0 V AC
FH-S: On/Off
3 LIVE O 120 V AC
220-240 V AC
AC power output to FM-M/S
YC4 1 +5V O 5 V DC 5 V DC power output to MPWB
Connected
to the main
PWB
2 +5V O 5 V DC 5 V DC power output to MPWB
3 +5VSL O 5 V DC 5 V DC power output to MPWB
4 +12VSL O 12 V DC 12 V DC power output to MPWB
5 +24VSL O 24 V DC 24 V DC power output to MPWB
6 GND - - Ground
7 GND - - Ground
8 GND - - Ground
9 GND - - Ground
10 GND - - Ground
YC5 1 GND - - Ground
Connected
to the inter-
face PWB
2 +5V O 5 V DC 5 V DC power output to IFPWB
YC6 1 FAN3DRN O 0/24 V DC CFM3: On/Off
Connected
to the cool-
ing fan
motor 3
2 +24VSL O 24 V DC 24 V DC power output to CFM3
